Materials
Glass
CRI (clear)
Handmade glass pearls
Finishes
Possible arrangements
SUSPENSION
Overall drop can be adjusted on site. Supplied with Ø 190mm (7.5”) or Ø 250mm (10”) ceiling canopy and 2000mm (79”) cable.
FIXING
Ceiling plate with 4 fixing slots provided (fixings not included). Ceiling plate is suitable for use with a 3.5” octagonal junction box. Please ensure fixings and junction box are suitable to carry the weight indicated.
INSTALLATION
Fixture requires on site assembly by a qualified electrician.
Electricals
LAMP
240V/120V warm white LED tape (2600K):
Ø 400 – 4300Lm
Ø 600 – 6500Lm
Ø 800 – 8650Lm
Ø 1000 – 10350Lm
Ø 1200 – 12950Lm
POWER
24V LED tape with power output of:
Ø 400 – 58W
Ø 600 – 87W
Ø 800 – 116W
Ø 1000 – 144W
Ø 1200 – 173W
Supplied with 24V constant voltage mains
dimmable transformers. Trailing edge dimming is
recommended for best results. Transformers are housed within ceiling canopy. Full transformer specification available upon request.
1-10v and DALI dimming options are available by
request, requires an additional cable circuit to
be provided, please consult your electrician for
suitability.
STANDARD
All lighting is made to CE standard.
LED tape and transformer both UL recognised.
